ChargePoint Express 250 5 Year Software + Warranty Bundle 62.5kW Level 3 DC Fast Charger Charging Station
Regular price
$59,500.00
Sale price
$70,000.00
Shipping calculated at checkout.
The ChargePoint CPE250C-625-CCS1-200A-CHD is one of the most popular Level 3 DCFC chargers on the market. Drivers have the ability to start a charging session using a mobile APP, RFID, or an NFC tap to charge. The cloud-based software allows the station administrator to access and monitor the station remotely.
Included with this bundle is both 5 Year Software and 5 Year Warranty:
- Network (CPCLD-ENTERPRISE-DC-1): 5-Year Commercial Cloud Plan
- Activation (CPSUPPORT-ACTIVE): one-time activation
- Installation (CPE250-TOOLKIT-F and DC-UNIVERSAL-CMT-METRIC): Tool kit and mounting bracket
- Site Validation (CPE250-COMMISSIONING): Required to activate the Assured Warranty
- Assured Warranty (CPE250-ASSURE-1): 5-year warranty that includes parts and labor, remote technical support, on-site repairs when needed, unlimited configuration changes, and reporting.
Chargepoint DC 250 Express Spec Sheet
ChargePoint CPE250C-625-CCS1-200A-CHD 5 Year Bundle Package 62.5kW Level 3 DCFC Express 250 Station Includes 2 Power Modules, a CCS and CCS OR CCS and CHAdeMO Cable options available.
- Level 3 DCFC 62.kW
- Dual Port: CCS1 and CHAdeMO Cables
- Input Rating
- 400V AC 3-Phase 96A 50hZ
- 480Y/277V AC 3-Phase 80A 60hZ
- Max Output: 62.5kW (120kW max pair output)
- Output Voltage: 200-1000V DC
- Max Output Current: 156A
- Max Modules Per Station: 2
- Cable Length: 14ft
- LCD Display: Full color 10" display for driver interaction
- Top Display: Full color 20" LED display for notification
- Authentication
- RFID: ISO 15693 and ISO 14443
- Tap to Charge: NFC on compatible Apple and Android devices 15118-2
- Connectivity
- Cellular: 4G LTE (3G when 4G unavailable)
- WiFi: 5GHz and 2.4 GHz
- Safety and Compliance
- Type 3R, IP54, IK10, UL, cUL and CE
- Surge Protection IEC 6100-4-5 Level 5 6kV at 3000A
- FCC part 15 Class A
- Temperature: -40F to 122F
